Tel Rad, S.A. MARGULES AUDIO

Is a family-owned organisation that performs research, design, and manufacture of amplifiers, preamplifiers and loudspeaker systems with total commitment to quality. The history of the family in the reproduction of sound dates back to 1926 when Jacobo Margules founded Emporio Electrico, which later became Casa Margules specialising in electronic components for radio broadcasters, radio amateurs, service technicians and students. That later became Radio Surtidora S.A. Now the oldest organisation in Mexico. The company also was involved in the sound reproduction field, when high fidelity became possible, introducing it in our country. Currently Radio Surtidora specialise in electronic measurement equipment and industrial electronic components.


ΜΕΡΙΚΑ ΑΠΟ ΤΑ ΠΡΟΪΟΝΤΑ:

Preamplifier SF220r.
High end tube preamplifier, with all functions remote controlled, uses 5 tubes, 12AU7, 12AX7, 6DJ8 mirror image design






Tube amplifier TR2200sc
Two mono blocks in Pure Class A, tube audio amplifier, servo-controled output , high precision regulated voltage in the input and inverter tubes, active damptput impedance, independent gain control for each channel, precision metal film resistors, polypropylene capacitors 16 output tuing control, bias meter, 220W/channel, can work triode or ultralinear, variable oubes, can use 6550, KT99, KT88, KT100.




The Grand Orpheus

Has been the most ambitious loudspeaker project made by Margules Audio.

The Grand Orpheus incorporates our constantly developed expertise, true craftmanship and years of accumulated experience, with the best available components resulting in a outstanding solid performance loudspeaker. It was engineered for extremely accurate sweet dynamic sound that reveals spectacular detail, unveiling the most subtle variations with astonishing transparency. The Grand Orpheus uses four drivers in a four way configuration with an active subwoofer in three separated units per channel
With Active Subwoofer. Custom finish.




Για περισσότερες πληροφορίες:
http://www.margules.com.mx/home.htm


Στην Ευρώπη κυκλοφορούν στην Ελβετία και στην Ιταλία νομίζω.



Μηνύματα
3.074
Reaction score
650
Ω! ναι ! Άντε την επόμενη θα σας δείξω τα Audiopax του Eduardo Da Lima.



Από το






με αγάπη: :D



Μηνύματα
3.074
Reaction score
650
Nαι οι τελικοί model KT88 single ended με λυχνίες ΚΤ 88 σε τριοδική συνδεσμολογία.




Specifications


Type: Single-ended tube monoblock
Tube Complement: 2 x KT88 power tubes, 2 x 12AT7 driver tubes
Chassis: consists of central chrome-plated solid brass bridge with wooden or lacquered side cheeks and plinth, chromed handles and stand-offs and gold-plated front-mounted name decal.
Rear panel: circuit breaker acts as fuse-less power switch and activates a relay to prevent in-rush current
Cardas rhodium-plated 5-way binding posts and RCA input jack
Max Power Output: 30 Watts RMS at 1kHz into 8 ohms


Kαι τα ηχεία Ref 100





The AUDIOPAX REF100 loudspeaker is the result of extensive research into the interface of loudspeakers and amplifiers. It was designed to be an ideal match for low-feedback tube amplifiers, including single-ended types. Since it is an easy load and has a very transparent and open sound quality, it can also be used with solid state amplifiers of very high quality.

Features:
This loudspeaker's exceptional musical performance is achieved as the result of carefully blending the findings of our research with a few unusual construction techniques. The twin cabinet design is built from 1 1/8" (2.8mm) and 2" (50mm) braced MDF, keeping its own resonances not only at low levels but also the least intrusive frequencies.

The 8" midrange driver was developed in-house and made to be a very quick and transparent transducer without using any overkill techniques. We have balanced the use of very old and quite new technology in the musically most significant way we could think of. The magnet is large without being overly huge which would introduce its own problems. The voice coil is wound on a Kapton former that optimally couples to the hand-coated paper cone. A solid brass phase plug and a treated cloth suspension complement our recipe of a very transparent and dynamic mid-range unit.

Low frequencies are handled by a 10" woofer also of our own design. Used in a non-standard bass reflex alignment, it can reproduce deep low frequencies without losing the quickness and superb transient response necessary to produce coherence with the mid-band. It too is a paper cone driver designed with the same basic ideas as used in the midrange. It would be hard to point at any one specific detail that is solely responsible for its extraordinary performance which Jules Coleman of 6moons.com called "the most significant loudspeaker introduction at CES 2004". It is rather the way in which all the different details interact that make this AUDIOPAX woofer work so well.

For the high frequencies, we use a unit that is probably the best high-frequency driver available and certainly the one that best matched the resolution, speed and smoothness of the other drivers: A dual ring radiator with very extended frequency response to 40kHz!

All drive units are integrated by our proprietary crossover that properly takes the relevant driver characteristics into account. The integration is seamless and smooth. The crowning touch is the choice of piano black or metallic gloss lacquer finishes in different colors to make the REF100s' visual appearance match the sound they can deliver.

Specifications:
Frequency response: 35Hz to 40kHz
Crossover points: 250Hz (6dB/oct) and 3200Hz (12dB/oct)
Sensitivity: 92dB/2.83V/m
Nominal impedance: 8 ohms
Minimum impedance: 6.5 ohms
Recommended amplifier power: 5W to 80W
Dimensions: 45" (115cm) H x 9.5" (28cm) W x 22" (55cm) D
Net weight: 84 lbs. (40 Kg)

Αντιγραφή από το site της εταιρείας
