AUDIO 4 Ηλεκτροστατικά ηχεία από την Ολλανδία
The ESL 65-8 is a loudspeaker for people that are not satisfied with less than complete expression of music/sound. And who doesnt want to hear his favourite orchestra or singer live like in their living room?
Our starting point with production and supply of the loudspeaker ESL 65-8
They are handmade
In doing so we keep in touch with your personal wishes
We thoroughly test them ourselves
We deliver made to order
We give garanty for ten years
We will put your ESL 65-8 together after a written order has been received and your advanced payment of 25% of the price has been received.
Price per set loudspeakers
Description Type Price
Monitor ESL65-8.5 mk 5 E 7950,=
Time of delivery is 3 months after we have received your order and payment.
a detail of the bas-unit: the stator.
Technicals Details
low-unit high-unit
frequences 10-4000 Hz 200-22.000 Hz
surface 0,6 m2 0,08 m2
step-up 1:250 1:60
high tension 2200 volts 1000 volts
membrane thickness 12 micron (½ mil) 12 micron (½ mil)
capacity 1100 pF 175 pF
statordistance 2 mm (80 mil) 0,9 mm (35 mil)
wire thickness stator 0,15 mm2 0,05 mm2
resonance frequency 22 Hz
type stators wire
total weight 9 kg (18.2 pounds)
high 114 cm (3.45 feets)
width 79 cm (2.39 feets)
thickness 6 cm (2.4 inches)
hinge from the wall 60 cm (1.8 feets)
ΠΕΡΙΣΣΟΤΕΡΑ:
http://www.audio4.nl/enprod01.htm
