- First production digital processor with cryogenically treated electronic circuits. Cryogenic treatment of the assembled PC boards raises the DA-218's musicality to a new-state-of-the-art reference.
- New nonmetallic shielding that protects the analog circuits from RFI / EMI noise interference, thus protecting the DA-218's neutral tonality and pure sound quality.
- New Up and Over-sampling software that gives you an in-the-hall appreciation of the music's sound stage, transients and air.
- New shielded Quantum Noise Filters that are custom made for the DA-218. Quantum Noise Filters added to the AC mains lower the analog noise floor, increasing dynamics and resolution.
- New 4 layer PC Boards. These materials were very carefully chosen by both measurement and critical listening to sustain the very purest analog music.
- Custom capacitors made especially for the DA-218 are used in the analog section. These custom capacitors are made with special dielectrics that further nourish the textural timber of the musical image.
- Sonically critical plug-in assembles are hand assembled, hand soldered and then each one is tested with the very latest test equipment to ensure the technologically advanced musical performance from each processor
Specifications:Three Digital Inputs, Standard (Coax-1) S/P DIF input via RCA
(Coax-2) S/P DIF input via BNC
(Optical) EIAJ Plastic Fiber Optic TosLink
Fourth Digital Input, Optional (AUX) AES/EBU Balance via XLR
Two Analog Outputs Left & Right Single-ended via RCA
Left & Right Balanced via XLR
Output Level 2.3 Volts RMS Single-ended
Frequency Response 10 Hz to 100 KHz
Output Impedance 75 Ohms Single-ended, 150 Ohms Balanced
Channel Separation >120 db @ 1 KHz
Signal Inverting Digital Domain
Sampling Frequencies 32 KHz, 44.1 KHz and 48 KHz, 96 KHz (automatically selected)
Modularity/Upgradeability The Upsampler module, Microprocessor, Digital filter and Analog IC's are Socketed for future format upgrades
Power, International 105/220 VAC 50/60 Hz via IEC connector
Power Consumption 58 Watts @ 120 volts, 60 Hz
Dimensions 3" High, 17" Wide, 12" Deep
Silver front faceplate is standard.
A black front faceplate is available with special order request.
Weight 18 lbs.
Warranty Three (3) Year, Transferable Warranty
Price: $ 8,900.00
- Και αυτό που σκεφτήκατε να ρωτήσετε... κι αυτό το κάνει.....
- Δείτε το review στους Stereo Times.
