MODEL 1
From Toronto CANADA
Specifications
Speaker type - Floor standing sculptured tower with a dynamic 2 1/2 way, 3 speaker system and bass reflex loading
Continuous power rating - 150 Wrms system power
Frequency response - 32 Hz 20kHz +/- 3db
Efficiency - 97 db/w/m
Recommended amplifiers - 3.5 300 Wrms into 8 ohms
Crossover frequency - 2,200 Hz acoustic
- 80 Hz acoustic low pass filtering of rear woofer
Impedance - 6 ohms nominal with minimal impedance variation
Dimensions - 16 W x 18 D x 45 Ό H
- 41cm W x 46cm D x 115cm H
Net weight - approx 150lbs, 68kgs
Cabinet - Front wall constructed with a proprietary 1 ½ / 37mm laminate of MDF, plastic and cotton, that has a broadband attenuation of 46 db
- Select panels are damped with a lead, rubberized bitumen laminate
- Extensive internal bracing used throughout
Crossover - Audiophile, premium grade components and wiring tuned for a smooth frequency response with minimal off axis variation and low system distortions
Woofer - Two 10 / 25cm, 200 Wrms drivers each with a cast basket, rough molded heavy paper cone, doped and pleated cloth surround, massive focused 90oz. magnet and 3 / 75mm voice coil
- Linear Xmax of +/- 4.5mm
Tweeter Precision machined aluminum faceplate with phase plug, aluminum dome, braided lead wires and a powerful magnet system without liquid cooling for maximum transient performance and efficiency
Price: Sandstone or Blue black/USD$7699.00 High gloss USD$8999.00
