leandros
Πάρτε παθητικά!
- Μηνύματα
- 3.204
- Reaction score
- 6.113
Most visitors online was 2716 , on 5 Dec 2023
-
Καλώς ήρθατε στο AVsite! Ελάτε στην παρέα μας κάνοντας εγγραφή!
- Μηνύματα
- 55.283
- Reaction score
- 137.938
Πλασεμπο εφεκτ Νο.2....
The better fidelity you hear including "air" and "imaging" when you swap out your generic cable for premium cables is not there because the sound has changed. It is there because your mind has! You swap cables, focus more on what you are playing and all of a sudden hear better separation of notes, lower noise floor, etc. All of these were always there. It is just that your brain would explode if it had to remember all this detail so it normally ignores them until you start to compare audio components/tweaks. So we know why you "hear" a difference. A difference is there in your mindset.
Σκότωσε ένα κιμπερ ο Αμίρ.
Το έθαψε κιόλας.
Μοίρασε και κόλλυβα.
The better fidelity you hear including "air" and "imaging" when you swap out your generic cable for premium cables is not there because the sound has changed. It is there because your mind has! You swap cables, focus more on what you are playing and all of a sudden hear better separation of notes, lower noise floor, etc. All of these were always there. It is just that your brain would explode if it had to remember all this detail so it normally ignores them until you start to compare audio components/tweaks. So we know why you "hear" a difference. A difference is there in your mindset.
Σκότωσε ένα κιμπερ ο Αμίρ.
Το έθαψε κιόλας.
Μοίρασε και κόλλυβα.
alexis
Reticular Activating System
- Μηνύματα
- 16.821
- Reaction score
- 30.749
GETTING WIRED
“There is not a day that goes by where I do not get asked what cable Bryston recommends with our amplifiers. Hopefully the following will assist you in weeding through some of these complex issues.
Part of the problem is that there is an awful lot of marketing going on and not much science in some cases. The ‘elaborate packaging’ of these interconnects and speaker cables may make you feel warm and fussy but the electrical characteristics are still the primary issue of concern. Simply stated the geometry (where the plus is relative to the minus) of a cable determines the inter-relationship between the measured performance of a specific cable. These measured performance criteria are called the ‘Primary Constants’. They are R–resistance, L–inductance, C–shunt capacitance and G–shunt conductance. You can play around with all types of exotic packaging and add-on appendages you like but ultimately the measured performance (primary constants) tell the tale.
Bryston does not think cables should be 'voiced' to sound a specific way. The best cable is NO cable at all so we contend that the best cable is the cable that changes the signal the least.
COAX INTERCONNECT CABLES:
An analogue Preamp/Amplifier connection is a ‘high impedance interface’ therefore; you are looking for low measured Capacitance. An interconnect cable acts like a capacitor in the signal path so the better that capacitor the better the interconnect. We use an interconnect wire with (very low capacitance) and the RCA connectors are made for us in Switzerland. The RCA cables ‘make and break ground’ first and last when connecting and disconnecting. This prevents ugly pops and bangs from going through your system with the possible negative results.
XLR INTERCONNECT CABLES:
The XLR cables we use are also very low in capacitance. Actually the XLR cable we are currently using is in fact low noise balanced microphone cable with 100% shield coverage against RF. The advantage of Balanced XLR cables is that they have a noise canceling effect known as ‘common mode noise reduction’. This helps prevent noise and hum from affecting your system. With today’s complexity of audio and video surround systems this is a big plus, so if you ‘got em-use em’.
DIGITAL CABLES:
With ‘Digital’ interconnects things are a lot different. The wavelengths of digital signals are ‘very short’ (same for FM) so the lengths and terminations are much more critical than with the analogue signals previously discussed. When the wavelength of the signal the cable is used for approaches 1/30th of the length of the cable then transmission line effects start to appear and much more attention has to be paid to the connection and termination. If not then reflections and cancellation of data is a real possibility. For instance the AES/EBU digital connection on the back of the Bryston SP3 and SP4 should be used with a cable having an impedance of 110 ohms.
VIDEO CABLES:
Video cables also operate at very high frequencies – typically 5-6 MHz for Composite and S-Video and 8-30 MHz for Component Video depending on the scan rate and resolution. So again understanding the wavelengths of the signals and interfaces involved is important.
SPEAKER CABLES:
The Amplifier/Speaker interface is a ‘low impedance’ connection. Therefore, in a speaker cable you are looking for low ‘self inductance’ (because inductance rolls off the top end) as opposed to ‘low capacitance’ required in the RCA or XLR analogue interconnect. For speaker cables we use a stranded 9 gauge linear crystal copper with ‘Heavily Gold plated’ Spade lugs or Expandable Banana plugs specially made for Bryston.
A/C POWER CABLES:
When you plug your power cord into the wall outlet you are in 'SERIES' with all the wire on the other side of the wall all the way back to the power source. The small length of power cord from the wall to the amp is insignificant compared to the miles of wire it is connected to. As long as the power cord can deliver the current and voltage required to drive the amplifier to full power it is as good as it can get.
There are 4 basic things to remember about these issues:
1. The connection should be of similar metals (preferably gold) and be airtight. If not airtight it will break down molecularly over time and begin to rectify or produce a diode effect on the signal.
2. With all the RF floating around today the better the ‘Shield’ on the interconnect the less intrusive the RF will be.
3. The connection between your analogue Source components (Preamplifier, CD Player, Tuner, DVD Player etc.) is a ‘High Impedance’ connection and the interface between your power amplifier and your speakers is a ‘Low Impedance’ connection. So, the requirements are totally different for optimizing these interfaces.
4. Digital and Video cables are much more susceptible to reflection/phase/cancellation problems because of their short wavelengths relative to cable length.
As you can see from the above, no surprise that people hear differences in cables when connected to the variety of equipment in the market today. Given the differences in input and output impedance’s between transistor and tube gear, the lack of understanding of the high impedance and low impedance interfaces, the world of RF, and the digital/video connection issues no wonder we have these differences of opinion.
RECOMMENDATIONS:
I highly recommend keeping the speaker wires as short as possible and utilizing XLR balanced lines if available. Given the choice of long interconnects and short speaker leads or short interconnects and long speaker leads – choose long interconnects (preferably Balanced) and short speaker leads. With digital and video cables finding out the sending and termination requirements is very important due to the very short wavelengths relative to cable lengths involved.
The cables Bryston recommends represent a scientific approach to these issues and are the cables we use in all our professional studio installations. All of these cables are available through Bryston’s Website (www.bryston.com) or our dealers if you wish.
ADDENDUM:
The line cords we supply for the 14B and 28B are 12 ga. That's more than large enough to draw 15 Amps out of the wall. 12A is the largest breaker we are allowed to put in any of our products, which is 80% of the plug rating. 12 Amps X 120V = 1440W., which is about what the amp will draw from the wall plug when delivering its rated 1000W.
An important thing to note is that the transformers used in the largest Bryston Amplifiers. (7B, 14B, 28B), are special 'energy storing' transformers. That means they don't need to draw large, narrow 'spikes' of current when charging the filter caps. Instead, the incoming current is largely sinusoidal, with a small peak-to-average ratio. The energy-storing transformers act almost like a large battery, delivering large current pulses from the secondary while the primary is charged by lower peak current from the wall.
We do offer a BIT (Bryston Isolation Transformer) power product but it is designed to ‘isolate your system’ from the rest of the equipment on the power line. It’s like having your own miniature power grid. It is not going to alter any of the issues discussed above.”
James Tanner
Bryston
“There is not a day that goes by where I do not get asked what cable Bryston recommends with our amplifiers. Hopefully the following will assist you in weeding through some of these complex issues.
Part of the problem is that there is an awful lot of marketing going on and not much science in some cases. The ‘elaborate packaging’ of these interconnects and speaker cables may make you feel warm and fussy but the electrical characteristics are still the primary issue of concern. Simply stated the geometry (where the plus is relative to the minus) of a cable determines the inter-relationship between the measured performance of a specific cable. These measured performance criteria are called the ‘Primary Constants’. They are R–resistance, L–inductance, C–shunt capacitance and G–shunt conductance. You can play around with all types of exotic packaging and add-on appendages you like but ultimately the measured performance (primary constants) tell the tale.
Bryston does not think cables should be 'voiced' to sound a specific way. The best cable is NO cable at all so we contend that the best cable is the cable that changes the signal the least.
COAX INTERCONNECT CABLES:
An analogue Preamp/Amplifier connection is a ‘high impedance interface’ therefore; you are looking for low measured Capacitance. An interconnect cable acts like a capacitor in the signal path so the better that capacitor the better the interconnect. We use an interconnect wire with (very low capacitance) and the RCA connectors are made for us in Switzerland. The RCA cables ‘make and break ground’ first and last when connecting and disconnecting. This prevents ugly pops and bangs from going through your system with the possible negative results.
XLR INTERCONNECT CABLES:
The XLR cables we use are also very low in capacitance. Actually the XLR cable we are currently using is in fact low noise balanced microphone cable with 100% shield coverage against RF. The advantage of Balanced XLR cables is that they have a noise canceling effect known as ‘common mode noise reduction’. This helps prevent noise and hum from affecting your system. With today’s complexity of audio and video surround systems this is a big plus, so if you ‘got em-use em’.
DIGITAL CABLES:
With ‘Digital’ interconnects things are a lot different. The wavelengths of digital signals are ‘very short’ (same for FM) so the lengths and terminations are much more critical than with the analogue signals previously discussed. When the wavelength of the signal the cable is used for approaches 1/30th of the length of the cable then transmission line effects start to appear and much more attention has to be paid to the connection and termination. If not then reflections and cancellation of data is a real possibility. For instance the AES/EBU digital connection on the back of the Bryston SP3 and SP4 should be used with a cable having an impedance of 110 ohms.
VIDEO CABLES:
Video cables also operate at very high frequencies – typically 5-6 MHz for Composite and S-Video and 8-30 MHz for Component Video depending on the scan rate and resolution. So again understanding the wavelengths of the signals and interfaces involved is important.
SPEAKER CABLES:
The Amplifier/Speaker interface is a ‘low impedance’ connection. Therefore, in a speaker cable you are looking for low ‘self inductance’ (because inductance rolls off the top end) as opposed to ‘low capacitance’ required in the RCA or XLR analogue interconnect. For speaker cables we use a stranded 9 gauge linear crystal copper with ‘Heavily Gold plated’ Spade lugs or Expandable Banana plugs specially made for Bryston.
A/C POWER CABLES:
When you plug your power cord into the wall outlet you are in 'SERIES' with all the wire on the other side of the wall all the way back to the power source. The small length of power cord from the wall to the amp is insignificant compared to the miles of wire it is connected to. As long as the power cord can deliver the current and voltage required to drive the amplifier to full power it is as good as it can get.
There are 4 basic things to remember about these issues:
1. The connection should be of similar metals (preferably gold) and be airtight. If not airtight it will break down molecularly over time and begin to rectify or produce a diode effect on the signal.
2. With all the RF floating around today the better the ‘Shield’ on the interconnect the less intrusive the RF will be.
3. The connection between your analogue Source components (Preamplifier, CD Player, Tuner, DVD Player etc.) is a ‘High Impedance’ connection and the interface between your power amplifier and your speakers is a ‘Low Impedance’ connection. So, the requirements are totally different for optimizing these interfaces.
4. Digital and Video cables are much more susceptible to reflection/phase/cancellation problems because of their short wavelengths relative to cable length.
As you can see from the above, no surprise that people hear differences in cables when connected to the variety of equipment in the market today. Given the differences in input and output impedance’s between transistor and tube gear, the lack of understanding of the high impedance and low impedance interfaces, the world of RF, and the digital/video connection issues no wonder we have these differences of opinion.
RECOMMENDATIONS:
I highly recommend keeping the speaker wires as short as possible and utilizing XLR balanced lines if available. Given the choice of long interconnects and short speaker leads or short interconnects and long speaker leads – choose long interconnects (preferably Balanced) and short speaker leads. With digital and video cables finding out the sending and termination requirements is very important due to the very short wavelengths relative to cable lengths involved.
The cables Bryston recommends represent a scientific approach to these issues and are the cables we use in all our professional studio installations. All of these cables are available through Bryston’s Website (www.bryston.com) or our dealers if you wish.
ADDENDUM:
The line cords we supply for the 14B and 28B are 12 ga. That's more than large enough to draw 15 Amps out of the wall. 12A is the largest breaker we are allowed to put in any of our products, which is 80% of the plug rating. 12 Amps X 120V = 1440W., which is about what the amp will draw from the wall plug when delivering its rated 1000W.
An important thing to note is that the transformers used in the largest Bryston Amplifiers. (7B, 14B, 28B), are special 'energy storing' transformers. That means they don't need to draw large, narrow 'spikes' of current when charging the filter caps. Instead, the incoming current is largely sinusoidal, with a small peak-to-average ratio. The energy-storing transformers act almost like a large battery, delivering large current pulses from the secondary while the primary is charged by lower peak current from the wall.
We do offer a BIT (Bryston Isolation Transformer) power product but it is designed to ‘isolate your system’ from the rest of the equipment on the power line. It’s like having your own miniature power grid. It is not going to alter any of the issues discussed above.”
James Tanner
Bryston
Last edited by a moderator:
alexis
Reticular Activating System
- Μηνύματα
- 16.821
- Reaction score
- 30.749
Αλλάξτε αυτό το πράγμα που μπλέκουν 2 συνεχόμενες αναρτήσεις. Μπλέκουν πράγματα που είναι διαφορετικά.
Παρακαλώ πολύ στο παραπάνω να σβήσει από
Date: Tue, 5 Nov 1996 13:08:50 -0500
και κάτω.
Ευχαριστώ
- - - - - - -
Έκανα ένα Google Doc το mail του John Dunlavy σχετικά με τα καλώδια γιατί είναι τεράστιο και δεν ανεβαίνει.
docs.google.com
Παρακαλώ πολύ στο παραπάνω να σβήσει από
Date: Tue, 5 Nov 1996 13:08:50 -0500
και κάτω.
Ευχαριστώ
- - - - - - -
Έκανα ένα Google Doc το mail του John Dunlavy σχετικά με τα καλώδια γιατί είναι τεράστιο και δεν ανεβαίνει.
John Dunlavy about Cables
Date: Tue, 5 Nov 1996 13:08:50 From: (Dunlavy Audio Labs) To: [email protected] (bass group) Subject: Cable Nonsense (Long) Having read some of the recent comments on several of the Internet audio groups, concerning audible differences between interconnect and loudspeaker cables, I co...
Last edited:
- Μηνύματα
- 42.884
- Reaction score
- 76.476
Όχι. Μπορείς να περιμένεις 15 λεπτά πριν το επόμενο post, ή να τα διαχωρίζεις με απόσταση ή γραμμή για όσο χρόνο έχεις δυνατότητα editing.
- Μηνύματα
- 28.849
- Reaction score
- 84.942
Ωραίο τυφλό συγκριτικό για dac+ placebo effect
www.audiosciencereview.com
My blind AB comparison: SMSL SU-8 - SMSL SP200 - Xduoo XD-05 - Shanling M5s - iPhone 7+
Hi everyone! I will try to make this post short: Based on everything I have learned here, I will do my blind test with all the equipment I have. And I wanted to share it here. Purpose: I want to confirm that every good dac is transparent and every good amp is just needed if a headphone needs...
www.audiosciencereview.com
- Μηνύματα
- 7.471
- Reaction score
- 12.240
Θα κάνω τον συνήγορο του διαβόλου. Αν ο δικός μου λόγος δεν μετράει ( που μπορεί να ακούω διαφορές ), γιατί θα πρέπει να μετράει ο δικός του λόγος...?Ωραίο τυφλό συγκριτικό για dac+ placebo effect
My blind AB comparison: SMSL SU-8 - SMSL SP200 - Xduoo XD-05 - Shanling M5s - iPhone 7+
Hi everyone! I will try to make this post short: Based on everything I have learned here, I will do my blind test with all the equipment I have. And I wanted to share it here. Purpose: I want to confirm that every good dac is transparent and every good amp is just needed if a headphone needs...
Επιπλέον, δυσκολεύομαι να πιστέψω ότι δεν υπάρχουν ακουστές διαφορές, με δεδομένο ότι κάθε μηχάνημα έχει διαφορετική σχεδίαση στο στάδιο εξόδου ( κυρίως σε αυτό, αν και επικρατεί η άποψη - όπως διαβάζω - ότι οι σημαντικότεροι παράγοντες είναι το αναλογικό στάδιο καθώς και αυτό της τροφοδοσίας ). Εκτώς αν μιλάμε για μηχανήματα που έχουν τα ίδια χαρακτηριστικά σε αυτούς τους τομείς, οπότε πάω πάσο.
leandros
Πάρτε παθητικά!
- Μηνύματα
- 3.204
- Reaction score
- 6.113
Αγαπημένε μου ντοκτορ,Πλασεμπο εφεκτ Νο.2....
The better fidelity you hear including "air" and "imaging" when you swap out your generic cable for premium cables is not there because the sound has changed. It is there because your mind has! You swap cables, focus more on what you are playing and all of a sudden hear better separation of notes, lower noise floor, etc. All of these were always there. It is just that your brain would explode if it had to remember all this detail so it normally ignores them until you start to compare audio components/tweaks. So we know why you "hear" a difference. A difference is there in your mindset.
Σκότωσε ένα κιμπερ ο Αμίρ.
Το έθαψε κιόλας.
Μοίρασε και κόλλυβα.
Σε κατανοώ απόλυτα!!....κι εγώ αν είχα...196 μέτρα ιντερκονεκτ και 30 ακροδέκτες όπως λες... περίπου 50 μέτρα καλώδια ρεύματος που θα χρειάζονταν 14 ποιοτικά schucko κι άλλα τόσα iec... Κι εγώ.. ίσως, λέω ίσως...να προσπαθούσα να .. θάψω τα καλώδια!!
Μπορεί και εγώ να έψαχνα απεγνωσμένα να βρω οτιδήποτε έχει αναρτηθεί στο διαδίκτυο που να υποστηρίζει την θέση μου..
Οικονομικά θα με βόλευε, και θα έλεγα ότι δεν είμαι ο μόνος...
Άλλωστε 5 κιλά κόλλυβα δε κάνουν ούτε 15€, ενώ για τα παραπάνω καλώδια-ακροδέκτες, θες αρκετές χιλιάδες ευρωπουλα!!
Επομένως, φιλ φρη!!
Κάνε κηδεία οπότε θες!!
Άλλωστε τα καλώδια έχουν τον απεθαντο!
Last edited:
- Μηνύματα
- 7.471
- Reaction score
- 12.240
Βέβαια, ο ντόκτορ έχει τιγκάρει στη διάχυση, την απορρόφηση και την ισοστάθμιση και μετρημένα έχει flat response ( ή τουλάχιστον μπορεί να έχει, αλλά θέτει target curves, anyway ) και όλα μετρημένα ως προς το αποτέλεσμα και με διορθωμένες φάσεις. Αν θέλει π.χ. αέρα, τσιμπάει μια συχνοτική περιοχή και του φέρνει μέχρι και ανεμοθύελλα.
- Μηνύματα
- 55.283
- Reaction score
- 137.938
Λέανδρε, για σένα φίλε:
www.avsforum.com
Double-Blind ABX Testing Proves All Power Cords Have an...
There's nothing quite like that last three feet of copper wire to make that solid connection between the electrical grid and an audio appliance. Amazing but true... meticulous double-blind testing has recently proven the efficacy of power cords when it comes to audio. It turns out...
- Μηνύματα
- 1.768
- Reaction score
- 2.803
Sorry κιόλας Λέανδρε αλλά μουσική ακούς καθόλου η με τα καλώδια και τα μηχανάκια ασχολείσαι συνεχώς;;
alexis
Reticular Activating System
- Μηνύματα
- 16.821
- Reaction score
- 30.749
Μετατρέψτε τώρα την ανθρώπινη αντίδραση και συμμετοχή στα Audio πράγματα.
Στο αγαπημένο "Hearing is believing".
- Μηνύματα
- 948
- Reaction score
- 2.994
Placebo επίσης είναι να ψάχνεις απεγνωσμένα στο διαδίκτυο αρεστά κείμενα σε μια προσπάθεια να κατευνάσεις τους φόβους και τις ανησυχίες σου.
Οχι εσύ, γενικά το λέω !
.
alexis
Reticular Activating System
- Μηνύματα
- 16.821
- Reaction score
- 30.749
Αυτό είναι Confirmation Bias.
- Μηνύματα
- 7.471
- Reaction score
- 12.240
Ε, όχι παίδες. Η αλήθεια είναι στις καμπύλες απόκρισης και φάσης. Γκε γκε?
- Μηνύματα
- 55.283
- Reaction score
- 137.938
Μπα, δεν είναι αυτό μέσα στην έννοια του πλασεμπο εφεκτ.
Η πίστη όμως, είναι:
Expectation to plays a potent role in the placebo effect. The more a person believes they are going to benefit from a treatment, the more likely it is that they will experience a benefit.
Τα συμπεράσματα, είναι απλά...
Λινκ...
Decembered
Μαϊμού
- Μηνύματα
- 18.146
- Reaction score
- 42.234
C
chrispo
Guest
Πλασεμπο εφεκτ Νο.2....
The better fidelity you hear including "air" and "imaging" when you swap out your generic cable for premium cables is not there because the sound has changed. It is there because your mind has!"......
Σκότωσε ένα κιμπερ ο Αμίρ.
.....
....για κουφό τον ¨ κόβω ¨, το φίλο σου..
leandros
Πάρτε παθητικά!
- Μηνύματα
- 3.204
- Reaction score
- 6.113
πολύ πιθανό, να είμαι μέσα στους 5-10 συμφορουμίτες που ακούν από 4-8 ώρες μουσική κάθε μέρα και με τις λιγότερες αλλάγες στον εξοπλισμό μου από πολλούς, μιας και έχω κατασταλλάξει εδώ και καιρό και το σύστημα μου με ικανοποιεί πλήρως.
Η δε συλλογή μου σε lp's και cd's είναι και μεγάλου εύρους και μεγάλου πλήθους...
μέχρι & άυλα διαθέτω για ...να στρώνω μηχανάκια
, μιας και είναι ο μόνος λόγος ύπαρξης τους προς το παρόν!
Η ενασχόληση με τα μηχανάκια είναι για άλλους @Alfee24 !..πχ εσένα!!
Εγώ απολαμβάνω τη μουσική μου!
Last edited:
- Μηνύματα
- 948
- Reaction score
- 2.994
....για κουφό τον ¨ κόβω ¨, το φίλο σου..
Δεν είναι κουφός.
“Ταλαιπωρείται” από Confirmation Bias.
.
