Apogee Slant 6
Specifications
Height 52½ inches
Width 14½ inches
Depth 14¼ inches
Bass driver 6.5" dynamic cone woofer
Midrange/tweeter 26" dipole aluminium ribbon
Max Sound Level 107db @ 4 meters
Sensitivity @ 3m 83.2dB (2.83V at 1m)
Frequency response 32Hz to over 25kHz
Crossover frequency 1kHz
Suggested amp power 50Wpc min 200Wpc max (8ohms)
Impedance nominal/minimum 6ohms / 4ohms
Weight 80lbs each
Finishes available Black Sand
Price (1996-7) $2500 (+$200 for magnetic shielding)
Apogee Slant 8
Specifications
Height 59½ inches
Width 17½ inches
Depth 17 inches
Bass driver 8" dynamic cone woofer
Midrange/tweeter 40" dipole aluminium ribbon
Max Sound Level 107db @ 4 meters
Sensitivity @ 3m ~86dB
Frequency response 26Hz to over 25kHz
Crossover frequency 1kHz
Suggested amp power 100Wpc min 200Wpc max (8ohms)
Impedance nominal/minimum 6ohms / 4ohms
Weight 120lbs each
Finishes available Black or Taupe Sand
Price (1996) $3995
Η Apogee εισήγαγε την σειρά των ηχειων Slant για να αντικαταστήσει τον υβριδικο Κένταυρο γύρω στο 1994 - 95. Δύο ηχεια παρηχθησαν για την αντικατάσταση των τριών Centaur. Το Slant 6 είχε 6 ½ "woofer κώνου και ένα 26" ριμπον. Το μεγαλύτερο υβριδικό, με την ονομασία Slant 8 είχε ένα 8 "woofer, σε συνδυασμό με ενα τουίτερ ταινίας 40". Τα Slant 6 και 8 εκθειάστηκαν πολύ από τα περιοδικά ήχου της εποχης, και ήταν πολύ δημοφιλή.
Specifications
Height 52½ inches
Width 14½ inches
Depth 14¼ inches
Bass driver 6.5" dynamic cone woofer
Midrange/tweeter 26" dipole aluminium ribbon
Max Sound Level 107db @ 4 meters
Sensitivity @ 3m 83.2dB (2.83V at 1m)
Frequency response 32Hz to over 25kHz
Crossover frequency 1kHz
Suggested amp power 50Wpc min 200Wpc max (8ohms)
Impedance nominal/minimum 6ohms / 4ohms
Weight 80lbs each
Finishes available Black Sand
Price (1996-7) $2500 (+$200 for magnetic shielding)
Apogee Slant 8

Specifications
Height 59½ inches
Width 17½ inches
Depth 17 inches
Bass driver 8" dynamic cone woofer
Midrange/tweeter 40" dipole aluminium ribbon
Max Sound Level 107db @ 4 meters
Sensitivity @ 3m ~86dB
Frequency response 26Hz to over 25kHz
Crossover frequency 1kHz
Suggested amp power 100Wpc min 200Wpc max (8ohms)
Impedance nominal/minimum 6ohms / 4ohms
Weight 120lbs each
Finishes available Black or Taupe Sand
Price (1996) $3995

Η Apogee εισήγαγε την σειρά των ηχειων Slant για να αντικαταστήσει τον υβριδικο Κένταυρο γύρω στο 1994 - 95. Δύο ηχεια παρηχθησαν για την αντικατάσταση των τριών Centaur. Το Slant 6 είχε 6 ½ "woofer κώνου και ένα 26" ριμπον. Το μεγαλύτερο υβριδικό, με την ονομασία Slant 8 είχε ένα 8 "woofer, σε συνδυασμό με ενα τουίτερ ταινίας 40". Τα Slant 6 και 8 εκθειάστηκαν πολύ από τα περιοδικά ήχου της εποχης, και ήταν πολύ δημοφιλή.
